Cummins 60Hz
Cummins series adopt Cummins engine. Through near 10 years of cooperation with Cummins, Cummins series with its high reliability, low use and maintenance cost win the loyalty of many customers in Columbus, Indiana, Cummins Inc. serves customers in more than 137 countries and territories through its network of 680 company-owned and independent distributor locations and more than 500 dealer locations. As the largest foreign engine investors of China, Cummins possess Chongqing Cummins Engine Co., Ltd (produce M, N, K series engine) and Dongfeng Cummins Engine Co., Ltd (produce B, C, L series engine) and produce Cummins engines with globally uniform quality standard. Cummins guarantee the most convenience and shortcut service through their service network countrywide.
TECHNICAL SPECIFICATIONS
|
Model |
FKS-C25B |
FKS-C38B |
FKS-C60 |
FKS-C100 |
FKS-C110 |
FKS-C130 |
FKS-C180 |
FKS-C215 |
|||||||
|
Engine |
|
4B3.9-G2 |
4BT3.9-G2 |
4BTA3.9-G2 |
6BT5.9-G2 |
6BTA5.9-G2 |
6BTAA5.9-G2 |
6CTA8.3-G2 |
6CTAA8.3-G2 |
||||||
|
Standby power |
KW |
25 |
38 |
60 |
100 |
110 |
130 |
180 |
215 |
||||||
|
KVA |
31.25 |
47.5 |
75 |
125 |
137.5 |
162.5 |
225 |
268.75 |
|||||||
|
Prime power |
KW |
23 |
35 |
55 |
91 |
100 |
118 |
164 |
195 |
||||||
|
KVA |
28.75 |
43.75 |
68.75 |
113.75 |
125 |
147.5 |
205 |
243.75 |
|||||||
|
Rated current |
A |
41.4 |
63 |
99 |
163.8 |
180 |
212.4 |
295.2 |
351 |
||||||
|
Consumption |
Diesel |
L/H |
6 |
9 |
13 |
22 |
25 |
30 |
38 |
43 |
|||||
|
Motoroil |
g/kw.h |
1.08 |
1.07 |
1.08 |
1.07 |
1.07 |
1.07 |
1.06 |
1.06 |
||||||
|
Cylinders |
|
4 |
4 |
4 |
6 |
6 |
6 |
6 |
6 |
||||||
|
Bore×Stroke |
mm |
102×120 |
102×120 |
102×120 |
102×120 |
102×120 |
102×120 |
114×135 |
114×135 |
||||||
|
Displacement |
L |
3.92 |
3.92 |
4.92 |
5.88 |
5.88 |
5.88 |
8.3 |
8.3 |
||||||
|
Exhaust |
L/S |
67.5 |
101 |
130 |
250 |
272 |
293 |
519 |
519 |
||||||
|
Exhaust temperature |
℃ |
380 |
460 |
463 |
526 |
548 |
481 |
536 |
550 |
||||||
|
Engine oil capacity |
L |
9 |
9 |
11 |
16 |
16 |
16 |
24.3 |
24.3 |
||||||
|
Cooling-water capacity |
L |
20 |
20 |
25 |
25 |
25 |
25 |
28 |
28 |
||||||
|
Genset Dimention(mm) |
L |
1650 |
1722 |
1790 |
2350 |
2350 |
2350 |
2450 |
2500 |
||||||
|
W |
730 |
730 |
730 |
790 |
790 |
790 |
950 |
950 |
|||||||
|
H |
1070 |
1070 |
1220 |
1250 |
1250 |
1250 |
1320 |
1380 |
|||||||
|
Net weight |
KG |
600 |
680 |
750 |
970 |
1050 |
1200 |
1350 |
1520 |
||||||
|
Model |
FKS-C240 |
FKS-C300 |
FKS-C310 |
FKS-C350 |
FKS-C380 |
FKS-C410 |
FKS-C450 |
FKS-C500 |
|||||||
|
Engine |
|
6LTAA8.9-G2 |
NTA855-G1 |
NTA855-G2 |
NTA855-G3 |
KTA19-G2 |
KTA19-G2 |
KTA19-G3 |
KTA19-G4 |
||||||
|
Standby power |
KW |
240 |
280 |
310 |
350 |
380 |
410 |
450 |
500 |
||||||
|
KVA |
300 |
350 |
387.5 |
437.5 |
475 |
512.5 |
562.5 |
625 |
|||||||
|
Prime power |
KW |
227 |
250 |
280 |
320 |
350 |
380 |
400 |
450 |
||||||
|
KVA |
283.75 |
312.5 |
350 |
400 |
437.5 |
475 |
500 |
562.5 |
|||||||
|
Rated current |
A |
408.6 |
450 |
504 |
576 |
630 |
684 |
720 |
810 |
||||||
|
Consumption |
Diesel |
L/H |
48 |
62 |
70 |
62 |
83 |
83 |
97 |
106 |
|||||
|
Motoroil |
g/kw.h |
1.05 |
0.57 |
0.57 |
0.57 |
0.68 |
0.68 |
0.68 |
0.24 |
||||||
|
Cylinders |
|
6 |
6 |
6 |
6 |
6 |
6 |
6 |
6 |
||||||
|
Bore×Stroke |
mm |
114×135 |
125×147 |
140×152 |
125×147 |
140×152 |
140×152 |
140×152 |
159×159 |
||||||
|
Displacement |
L |
8.9 |
11 |
14 |
11 |
14 |
14 |
14 |
18.9 |
||||||
|
Exhaust |
L/S |
519 |
980 |
980 |
980 |
1047 |
1325 |
1532 |
1345 |
||||||
|
Exhaust temperature |
℃ |
430 |
480 |
560 |
532 |
550 |
484 |
998 |
524 |
||||||
|
Engine oil capacity |
L |
27.6 |
38.6 |
38.6 |
38.6 |
38.6 |
38.6 |
38.6 |
50 |
||||||
|
Cooling-water capacity |
L |
30 |
62 |
62 |
62 |
62 |
62 |
62 |
95 |
||||||
|
Genset Dimention(mm) |
L |
2500 |
2700 |
2700 |
3150 |
3150 |
3150 |
3150 |
3250 |
||||||
|
W |
950 |
1120 |
1120 |
1120 |
1000 |
1120 |
1120 |
1245 |
|||||||
|
H |
1380 |
1380 |
1380 |
1535 |
1535 |
1535 |
1535 |
1765 |
|||||||
|
Net weight |
KG |
1520 |
2900 |
3000 |
3100 |
3100 |
3200 |
3500 |
4300 |
||||||
|
Model |
FKS-C550 |
FKS-C580 |
FKS-C660 |
FKS-C800 |
FKS-C900 |
FKS-C1000 |
FKS-C1250 |
|||||||
|
Engine |
|
KTAA19-G5 |
KTAA19-G6A |
KT38-G |
KTA38-G2 |
KTA38-G2A |
KTA38-G4 |
KTA38-G9 |
||||||
|
Standby power |
KW |
550 |
580 |
660 |
800 |
900 |
1000 |
1100 |
||||||
|
KVA |
687.5 |
725 |
825 |
1000 |
1125 |
1250 |
1375 |
|||||||
|
Prime power |
KW |
500 |
530 |
600 |
730 |
800 |
910 |
1000 |
||||||
|
KVA |
625 |
662.5 |
750 |
912.5 |
1000 |
1137.5 |
1250 |
|||||||
|
Rated current |
A |
900 |
954 |
1080 |
1314 |
1440 |
1638 |
1800 |
||||||
|
Consumption |
Diesel |
L/H |
113 |
128 |
140 |
167 |
188 |
201 |
230 |
|||||
|
Motoroil |
g/kw.h |
0.24 |
0.24 |
0.24 |
0.24 |
0.24 |
0.24 |
0.24 |
||||||
|
Cylinders |
|
6 |
6 |
12 |
12 |
12 |
12 |
12 |
||||||
|
Bore×Stroke |
mm |
159×159 |
159×159 |
159×159 |
159×159 |
159×159 |
159×159 |
159×159 |
||||||
|
Displacement |
L |
18.9 |
18.9 |
37.8 |
37.8 |
37.8 |
37.8 |
37.8 |
||||||
|
Exhaust |
L/S |
1434 |
2054 |
2398 |
2936 |
3051 |
3967 |
3539 |
||||||
|
Exhaust temperature |
℃ |
538 |
584 |
524 |
527 |
499 |
530 |
540 |
||||||
|
Engine oil capacity |
L |
50 |
50 |
135 |
135 |
135 |
179 |
204 |
||||||
|
Cooling-water capacity |
L |
95 |
95 |
290 |
290 |
290 |
2150 |
2265 |
||||||
|
Genset Dimention(mm) |
L |
3650 |
3650 |
4400 |
4400 |
4400 |
5070 |
5341 |
||||||
|
W |
1550 |
1550 |
1800 |
1750 |
1750 |
2075 |
2108 |
|||||||
|
H |
2000 |
2000 |
2315 |
2315 |
2315 |
2211 |
2332 |
|||||||
|
Net weight |
KG |
4700 |
5200 |
9450 |
9600 |
9600 |
9800 |
9800 |
||||||
